Bosch Intelligent System with Performance CX electric drive. Kiox 300 display and 750 Wh battery.
160mm travel FOX 36 Factory suspension fork and 150mm FOLD kinematic mechanism with FOX X Performance damper
High precision and ultra-reliable: Shimano XT 1×12 gears and 4-piston brakes with fully integrated CIS cable routing and DT Swiss H1900 wheels
Bosch CX Electric Drive and 750 Wh Battery
160mm FOX 36 Factory fork and 150mm FOX X Performance rear shock
Shimano XT 1×12 and DT Swiss H1900 wheels
Powerful and dynamic electric assistance:
The efficient Bosch Performance CX electric drive system (fourth generation) provides a powerful torque of 85 Nm and a top speed of 25 km/h. The most powerful motor from Bosch is perfectly integrated and the JAM² is very maneuverable. In eMTB mode, the motor adjusts optimally to your riding performance. The Bosch Powertube battery is perfectly integrated in the down tube. The battery can be removed and charged at any time, or the charger can be plugged directly into the bike. Thanks to the 750 Wh battery capacity, you can easily master all mountain biking routes.
Our FOLD chassis is tailor-made for
the higher demands of an e-MTB. That’s why we’ve made sure the E-All-Mountain JAM² has the perfect suspension combination: FOLD is extremely responsive, yet progressive enough to prevent the damper from bottoming out.
The bike comes almost fully assembled. All you have to do is straighten the handlebars and attach the pedals.
| frame | 7005 Hydroformed Aluminum. 3D Forged. 150mm FOLD Motion. 148x12mm Thru Axle. Internal Cable Routing. 203mm Post Mount |
| Frame shape | Mountain Biking |
| Material | aluminum |
| gender | Unisex |
| weight | About 25.0 kg |
| Maximum weight allowed | 150 kg |
| fork | FOX 36 Float Factory 29. Grip 2. 110 x 15 mm. 44 mm Rake |
| Silent | FOX Float X Performance. 210/55 mm. Hardware: 25.0 x 8.0. No Bushing |
| Manufacturer Switch Group | Shimano |
| Rear derailleur | Shimano Deore XT M8100。12速 |
| Number of gears | 1×12 |
| Circuit Type | Transmission gear |
| crank | RaceFace Aeffect R e-Optimized Bosch G4 |
| Cassette tape | Shimano SLX-M7100. 12-speed |
| Drive Type | Chain drive |
| Free Fall/Resignation | flywheel |
| With pedal | No |
| wheel | DT SWISS H1900. 30-622. 15×110 mm / 12×148 mm |
| Wheel size | 29 inches |
| tire | Schwalbe Magic Mary. 2.6 Supercross soft. 65-622. Schwalbe Big Betty. 2.6 Supercross soft. 65-622 |
| Manufacturer Engine | Bosch |
| engine | Bosch Performance CX |
| Maximum Torque | 85 Nm |
| scope | Up to 150 km |
| support | Up to 25 km/h |
| Battery Pack | Bosch 750Wh PowerTube |
| exhibit | Bosch Kiox 300 |
| brake | SRAM DB8. 4-piston. Hydraulic disc brake |
| handlebar | RaceFace Atlas 35. Aluminium. 820 mm. Rise: 35 mm. Sweep: 8° |
| Seatpost | Post Modern Dropper Seatpost PM-214. 34.9mm |
| Saddle | Fezik Terra Eden |
| Dry | FOCUS CIS Integrated. 50 mm. 0°. 35 mm. Aluminium |
| Accessories/Others | Charger included |
