Conquering new peaks
More power and more range, less weight
The Shimano EP8 electric drive system is not only powerful, but also lightweight, which is perfectly matched to the flexible geometry of JAM² 7.8. Our specially developed 720 Wh integrated rechargeable battery provides strong power for your long rides. You can also charge your device via the USB-C charging port on the top tube.
Optimized Kinematics:
With the further development of our acclaimed FOLD kinematics, the JAM² 7.8 now has an even more aggressive ride. We kept the FOLD’s popular position and changed the positioning of the kinematics in the frame to provide even better fatigue resistance. The characteristic curve is fully progressive, ensuring superb stability even in the jungle position. E-MTBs in particular benefit from a greater progression, due to the increased weight of the motor and battery. This feature allows you to easily master any trail, while the frame remains stationary, giving you enough comfort for long trail rides. In addition, the emphasis on cross-advanced design gives you greater freedom on the trail, giving your JAM² 7.8 even more freedom of movement.
More fun on the trails
Ride functionality is our mission. With JAM² 7.8, every ride is more fun. Agile and maneuverable geometry with a slim and compact design lets you fly over all trails, whether they are technical or slick. With the FLIP CHIP on the JAM² 7.8 linkage, you can adjust the geometry to suit your aggressive riding style. Starting from 65.5° up to 65°, the head tube angle can be varied to give you more downhill potential. In addition, the specially developed CIS design ensures a clean look of the cockpit and always ensures perfect shifting and braking. All cables run from the handlebars into the stem and through the headset into the frame. In addition, all essential parts are mounted in the accessory bag between the top tube and down tube.
Powerful SHIMANO EP8 E-Drive integrated electric drive system. 720 Wh battery
150mm spring travel with new folding kinematics for even more performance
Long life and reliable shifting: SHIMANO SLX components and four-piston brakes. And the fully integrated CIS cable routing system, simple appearance and excellent performance.
The bike comes almost fully assembled. All you have to do is straighten it out and attach the pedals.
| frame | 7005 hydroformed aluminum. 3D forged. 150mm FOLD GEN2 hub. 148x12mm thru-axle. Internal cable routing. USB-C port. 203mm post mount |
| Frame shape | Mountain Biking |
| Material | aluminum |
| gender | Unisex |
| Weight | About 25.0 kg |
| Maximum weight allowed | 150 kg |
| fork | Rock Shox 35 Gold RL 29 Boost* or DVO Diamond E3*. 110x15mm. 44mm radius |
| Silent | Rock Shox Deluxe Select. 210/55mm. Hardware: 25.0 x 8.0mm. No Bushing |
| Manufacturer Switch Group | Shimano |
| Rear derailleur | Shimano SLX M7100. 12-speed |
| Number of gears | 1×12 |
| Circuit Type | Early gear |
| crank | Samox EC40 ISIS |
| Cassette tape | Shimano Deore CS-M6100. 12-speed |
| Drive Type | Chain drive |
| Free Fall/Resignation | flywheel |
| Fluorinated pedals | No |
| rim | RaceFace AR30 Offset |
| Hub | Front wheel: Shimano MT410. 15×110 mm. Rear wheel: Shimano MT410. 12×148 mm |
| Wheel size | 29 inches |
| tire | MAXXIS MINION DHF. 63–622 |
| Manufacturer Engine | Shimano |
| engine | Shimano Steps EP8 |
| Maximum terrain | 85 Nm |
| scope | Up to 150 km |
| support | Maximum speed: 25 km/h |
| Battery Pack | Chapter 720 |
| exhibit | Shimano SC-E5003 |
| brake | Shimano MT520. Hydraulic disc brogue |
| handlebar | Handlebar: 800 mm. Rise: 35 mm. Sweep: 9° |
| Seatpost | Postmodern dropper seatpost PM-214. 34.9mm |
| Saddle | Focus Race SL |
| Dry | FOCUS CIS integrated. 50 mm. 0°. 35 mm. Aluminium |
| Accessories/Others | Oxide |
